220kV Composite Station Post Insulator:
Brife technical data for FZSW-220/12.5:
Rated Voltage | Height | Dry Arcing Distance | Creepage Distance | Specified Cantilever Load | Max. Design Cantilever Load | Max. Design Torsion Load | Power Frequency Withstand Voltage | Lightning Impulse Withstand Voltage |
220 | 2100±5 | ≥1922mm | ≥6300 | ≥12.5kN | ≥7.5kN | ≥2.4kN • m | ≥530, ≥395 | ≥950 |
Note: For other section lengths, or end fitting combinations, please contact our Line Power representative.
Raw Materials:
End Fittings | Core | Sheds and Housing |
Materials: Hot dip galvanized cast iron or cast steel | Epoxy & Glass Fiber | HTV Silicone Rubber |
Min. thickness of the galvanization: 86μm | Rod Diameter: Φ90mm | Color: Gray |
With advanced manufacture and test equipment and experienced technicians, our technology and quality are in the forefront of the same industry.
Some photos:
